PLENUM AIR FLOAT TABLE


PRODUCT DESCRIPTION

The PST Plenum Air Flotation Table is a heavy duty full plenum air flotation system, 1, 3 or 5 hp depending on table size. The full plenum air flotation chamber is fabricated from two ¾” layers spaced apart and can be provided with random air flotation system.



MECHANICAL FEATURES

The superiorly constructed table base and top frame consist of heavy duty all MIG welded steel construction from 2” x 2” heavy wall tubular steel and can be used as either a free fall or break out table.

The tables base is equipped with jack screw legs for leveling and locking into place at the desired operating height which is adjustable from 34” to 37”. The table top is covered with abrasive resistant carpet and edged trimmed to prolong carpet life.

SPECIFICATIONS

Standard table is available in the following sizes:

48” x 96”
72” x 96”
94” x 120”
101” x 144”
120” x 144”.

OPTIONS

Custom sizes are available upon request.

Ships FOB Dallas, TX
