UNIWELD WATERJET BRICK & BOARD
Standard Duty Brick - 4mm
The 4mm Standard Brick is our most popular and most economical option with the lowest price in the marketplace. The 4mm Standard Brick option is ideal for Pure Water and Lite Abrasive users and is offered white in color with optional black for a surcharge.
The 4mm Standard Brick is our most popular and most economical option with the lowest price in the marketplace. The 4mm Standard Brick option is ideal for Pure Water and Lite Abrasive users and is offered white in color with optional black for a surcharge.
Medium Duty Brick - 6mm
The 6mm Heavy Duty Brick is ideal for Abrasive Cutting Applications and is slightly higher priced with increased durability and is offered white in color with optional black for a surcharge.
The 6mm Heavy Duty Brick is ideal for Abrasive Cutting Applications and is slightly higher priced with increased durability and is offered white in color with optional black for a surcharge.
*4 mm
Standard Duty
Most Popular
Most Economical
Standard Duty
Most Popular
Most Economical
*6 mm
Medium Duty
Abrasive Cutting
Medium Duty
Abrasive Cutting
*8 mm
Heavy Duty
Heavy Abrasive
5 Axis Applications
Heavy Duty
Heavy Abrasive
5 Axis Applications
*Flute size may vary with material lot
Top View: Welded Honeycomb Structure
Click on an image to view larger
Heavy Duty Brick - 8mm
The 8mm Professional Duty Brick is ideal for heavy abrasive and 5 axis cutting applications. The 8mm Professional Duty Brick is the heaviest wall construction in the industry for extended operating life and is offered white in color.
The 8mm Professional Duty Brick is ideal for heavy abrasive and 5 axis cutting applications. The 8mm Professional Duty Brick is the heaviest wall construction in the industry for extended operating life and is offered white in color.
Select your Material Grade
•
Provides a non-scratch , non- marking work surface.
•
Polypropylene material having no recycle fillers for increased durability.
•
Structural integrity - 100% THERMALLY WELDED, not limited to a partial weld.
•
No nails or screws installed, this eliminates delaminating and backsplash.
•
The no backsplash design yields cutting free of frosting marks.
•
Best selection in the industry to meet your specific need.
•
Three material grades offered - economy to heavy duty to meet your application.
•
12" width bricks reduce the number of brick seams by 50%.
•
2" thick bricks & boards at a 35% cost savings, ideal for pure water applications.
•
Board offering - 24" x 48" single piece - no seams, ideal for delicate cutting applications.
Best Selection / Factory Direct Pricing
Brick & Board Purchases Require a $400.00 Minimum Order
For information or to place an order via email wj@pstmfg.com
Download our line card
Click Shop above to browse our NEW e-commerce site
